Goodman GC9C96 Gas Furnace
Goodman GC9C96 downflow/horizontal two-stage 96% AFUE gas furnace: specs, sizing and warranty from Big Valley Heating.
The Goodman GC9C96 is the downflow and horizontal version of Goodman’s two-stage, multi-speed ECM gas furnace, rated up to 96% AFUE. It is the model to look at when the furnace has to blow downward — a common arrangement in homes where the furnace sits above the living space it heats.
Product Features
- Up to 96% AFUE two-stage condensing performance
- Multi-speed ECM blower motor
- Designed for downflow or horizontal installation
- Primary and secondary heat exchangers
- Low NOx configurations available
- Steel cabinet with a foil-lined heat-exchanger section
Specifications at a Glance
- Efficiency: up to 96% AFUE
- Heating stages: two-stage
- Blower: multi-speed ECM
- Heating input range: 40,000 – 100,000 BTU/h
- Example output (100,000 BTU/h model): 96,000 BTU/h, nominal 2,000 CFM
- Example cabinet (100,000 BTU/h model): 21" W × 34-1/2" H × 28-3/4" D
- Orientation: downflow or horizontal
- Venting: PVC (condensing furnace)
- Warranty: 10-year unit replacement and 10-year parts limited warranty when the unit is registered online within 60 days of installation; heat-exchanger coverage is extended on registration. Unregistered units fall back to the standard shorter term — we register yours for you.
Is the GC9C96 Right for Your Home?
Two-stage operation means the burner runs on low fire most of the time and only steps up to full output on the coldest days. In the Fraser Valley’s long stretch of mild, damp winter weather that is most of the season, so you get steadier room temperatures, quieter operation and fewer of the temperature swings a single-stage furnace produces. Choose the GC9C96 specifically when your ducting requires a downflow or horizontal furnace — the upflow GM9C96 is the equivalent unit for a standard basement installation.
Getting the Size Right
A furnace that is too large short-cycles, wears itself out and leaves uneven temperatures room to room. We size every replacement from a heat-loss calculation on your actual home — square footage, insulation, window area and orientation — instead of matching whatever was there before. Ask about current BC rebates before you decide; they can change which system makes financial sense.
Frequently Asked Questions
What is a downflow furnace?
A downflow furnace pulls return air in at the top and pushes heated air out the bottom. It is used where the furnace sits above the space it heats, such as a main-floor closet or utility room over a crawlspace.
How do I know which orientation I need?
Follow the existing ductwork — the direction of supply and return connections tells you. We confirm it on site before ordering anything.
Does the downflow model give up any efficiency?
No. The GC9C96 carries the same up-to-96% AFUE rating and the same two-stage, multi-speed ECM design as the upflow version.
Big Valley Heating & Sheet Metal installs this furnace across Maple Ridge, Pitt Meadows, Coquitlam, Port Moody, Anmore and the wider Fraser Valley. Because it is a condensing furnace, it vents through PVC rather than a traditional chimney, which affects where it can go in your home — something we confirm during the site visit, not after.
Ask Us About the GC9C96
We will tell you plainly whether this furnace suits your home or whether something else fits better. Request a free estimate, browse the rest of our equipment library, or read more about our heating services in the Fraser Valley.
